UPS PREVENTIVE MAINTENANCE SCOPE OF WORK
Perform a complete visual inspection of the equipment including subassemblies, wiring harnesses, contacts, cables and major components. Check air filters for cleanliness. Check UPS completely for the following (if applicable):
- Rectifier and inverter snubber boards for discoloration, burned or broken wires.
- AC Capacitors for swelling or leaking oil.
- DC Capacitor vent caps that have extruded more than 1/8”.
- Measure harmonic trap filter currents.
- Check all nuts, bolts, screws and connectors for tightness and heat discoloration.
- Check fuses on the DC capacitor banks for continuity (if applicable).
- With customer approval, perform operation test of the system including unit transfer, battery discharge and generator interface test.
- Calibrate UPS system specifications.
- Measure phase-to-phase input voltage and currents.
- Review, clear and reset all diagnostic alarm histories, where applicable.
- Record all input, output, and battery voltages and currents.
- Furnish completed data sheets and report any problems found during the PM inspection.
Note 1: Preventive Maintenance usually requires a UPS shut-down to ensure electrical connection integrity.
